Product Specification of PowerEdge R770 Rack Server
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (2 x Intel Xeon 6 Processors)
- Processor Family: Intel Xeon 6 (E-core and P-core series)
- Max Sockets: 2
- Max Cores per Socket: Up to 144 E-cores or 86 P-cores
- Max TDP: Up to 500 W per processor
- Max L3 Cache: Up to 480 MB per processor (varies by SKU)
- Memory Type: DDR5 RDIMM (registered ECC only)
- DIMM Slots: 32 DIMM slots (16 per processor)
- Maximum Capacity: Up to 8 TB
- Speed: Up to 6400 MT/s
- Protection: ECC with advanced RAS features
- Drive Bay Options: Up to 16 x EDSFF E3.S NVMe
- Configuration Option: 24 x 2.5-inch SAS/SATA/NVMe
- Configuration Option: 12 x 3.5-inch SAS/SATA
- Hybrid Configurations: Supported
- Supported Drives: SAS, SATA, NVMe SSD/HDD (2.5-inch, 3.5-inch, EDSFF E3.S)
- RAID Support: PERC H365i/H965i/H975i controllers (RAID 0, 1, 5, 6, 10, 50, 60)
- PCIe Slots: Up to 8 PCIe Gen5 slots (mix of x8/x16 full-height/full-length)
- OCP Slots: Up to 2 OCP NIC 3.0 (1/10/25/100/400 GbE)
- Networking: 1 GbE BMC + PCIe add-in cards (InfiniBand, 400 GbE, FC)
- GPU / Accelerator Support: Multiple GPU options with optional Direct Liquid Cooling
- Power: Redundant hot-plug PSUs (800W–3200W Platinum/Titanium)
- Cooling: Redundant hot-swap fans; optional Direct Liquid Cooling (DLC)
- Reliability: Hot-swap components, OCP DC-MHS modular design
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux (RHEL)
- Canonical Ubuntu Server LTS
- VMware ESXi
- SUSE Linux Enterprise Server (SLES)
- Dell SafeBIOS Secure Core
- System Lockdown and Cryptographic Erase
- Firmware Update Verification and TPM 2.0
- Secure Boot and Multi-Factor Authentication
- iDRAC10 Enterprise: Embedded remote management
- Dell OpenManage Enterprise: AI-driven centralized management
- APIs: Redfish APIs and RESTful interfaces for automation
- Standard Warranty: 3 Years ProSupport (parts, labor, onsite)
- Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms, AI-driven proactive analytics
-
Server Type / Form Factor
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (2 x Intel Xeon 6 Processors)
-
Processor (CPU)
- Processor Family: Intel Xeon 6 (E-core and P-core series)
- Max Sockets: 2
- Max Cores per Socket: Up to 144 E-cores or 86 P-cores
- Max TDP: Up to 500 W per processor
- Max L3 Cache: Up to 480 MB per processor (varies by SKU)
-
Memory (RAM)
- Memory Type: DDR5 RDIMM (registered ECC only)
- DIMM Slots: 32 DIMM slots (16 per processor)
- Maximum Capacity: Up to 8 TB
- Speed: Up to 6400 MT/s
- Protection: ECC with advanced RAS features
-
Storage
- Drive Bay Options: Up to 16 x EDSFF E3.S NVMe
- Configuration Option: 24 x 2.5-inch SAS/SATA/NVMe
- Configuration Option: 12 x 3.5-inch SAS/SATA
- Hybrid Configurations: Supported
- Supported Drives: SAS, SATA, NVMe SSD/HDD (2.5-inch, 3.5-inch, EDSFF E3.S)
- RAID Support: PERC H365i/H965i/H975i controllers (RAID 0, 1, 5, 6, 10, 50, 60)
-
Expansion / Connectivity
- PCIe Slots: Up to 8 PCIe Gen5 slots (mix of x8/x16 full-height/full-length)
- OCP Slots: Up to 2 OCP NIC 3.0 (1/10/25/100/400 GbE)
- Networking: 1 GbE BMC + PCIe add-in cards (InfiniBand, 400 GbE, FC)
- GPU / Accelerator Support: Multiple GPU options with optional Direct Liquid Cooling
-
Redundancy & Reliability
- Power: Redundant hot-plug PSUs (800W–3200W Platinum/Titanium)
- Cooling: Redundant hot-swap fans; optional Direct Liquid Cooling (DLC)
- Reliability: Hot-swap components, OCP DC-MHS modular design
-
Operating System Support
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux (RHEL)
- Canonical Ubuntu Server LTS
- VMware ESXi
- SUSE Linux Enterprise Server (SLES)
-
Security Features
- Dell SafeBIOS Secure Core
- System Lockdown and Cryptographic Erase
- Firmware Update Verification and TPM 2.0
- Secure Boot and Multi-Factor Authentication
-
Management & Monitoring
- iDRAC10 Enterprise: Embedded remote management
- Dell OpenManage Enterprise: AI-driven centralized management
- APIs: Redfish APIs and RESTful interfaces for automation
-
Warranty & Support
- Standard Warranty: 3 Years ProSupport (parts, labor, onsite)
- Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms, AI-driven proactive analytics
