Product Specification of Lenovo ThinkSystem SR650 V4
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (2x Intel Xeon 6 processors)
- Processor Family: Intel Xeon 6 (6700/6500-series P-cores, Granite Rapids-SP)
- Max Sockets: 2
- Max Cores per Socket: Up to 86 cores
- Max TDP: Up to 350 W per processor
- Socket Type: LGA 4710
- Memory Type: TruDDR5 (RDIMM, 3DS RDIMM, MRDIMM)
- DIMM Slots: 32x TruDDR5 RDIMMs + 16x MRDIMMs
- Maximum Capacity: Up to 8 TB
- Speed: Up to 6400 MHz (RDIMM), 8000 MHz (MRDIMM)
- Protection: Advanced ECC, RAS features
- Front Drive Bays: 24x 2.5" SAS/SATA/NVMe, 32x E3.S NVMe, or 12x 3.5" bays
- Mid Drive Bays: Up to 8x 2.5" SAS/SATA/NVMe
- Rear Drive Bays: Up to 8x 2.5" or 4x 3.5" SAS/SATA/NVMe
- Boot Drives: Up to 2x M.2 SATA/NVMe with RAID
- RAID Support: VROC NVMe SW RAID (0,1,5,10), PCIe RAID/HBA
- PCIe Slots: Up to 10x PCIe Gen5 slots
- OCP Slots: 2x OCP 3.0 slots
- Networking: OCP adapters, PCIe 10/25/100/200 GbE
- GPU Support: Up to 10x SW GPUs or 2x DW GPUs
- Power: Dual redundant AC/DC PSUs (Platinum/Titanium efficiency)
- Cooling: Lenovo Neptune Core/Air technology, redundant fans
- Reliability: Six nines uptime, hot-swap components
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
- Lenovo ThinkShield security suite
- Silicon Root of Trust
- Secure Boot and fTPM 2.0
- Federated directory security
- Lenovo XClarity Controller: Embedded management
- XClarity One: AI-driven analytics
- APIs: Redfish APIs for automation
- Standard Warranty: 3 Years Customer Replaceable Unit, Onsite NBD 9x5
- Optional Support: Premier Support, TruScale Infrastructure Services
-
Server Type / Form Factor
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Dual-socket (2x Intel Xeon 6 processors)
-
Processor (CPU)
- Processor Family: Intel Xeon 6 (6700/6500-series P-cores, Granite Rapids-SP)
- Max Sockets: 2
- Max Cores per Socket: Up to 86 cores
- Max TDP: Up to 350 W per processor
- Socket Type: LGA 4710
-
Memory (RAM)
- Memory Type: TruDDR5 (RDIMM, 3DS RDIMM, MRDIMM)
- DIMM Slots: 32x TruDDR5 RDIMMs + 16x MRDIMMs
- Maximum Capacity: Up to 8 TB
- Speed: Up to 6400 MHz (RDIMM), 8000 MHz (MRDIMM)
- Protection: Advanced ECC, RAS features
-
Storage
- Front Drive Bays: 24x 2.5" SAS/SATA/NVMe, 32x E3.S NVMe, or 12x 3.5" bays
- Mid Drive Bays: Up to 8x 2.5" SAS/SATA/NVMe
- Rear Drive Bays: Up to 8x 2.5" or 4x 3.5" SAS/SATA/NVMe
- Boot Drives: Up to 2x M.2 SATA/NVMe with RAID
- RAID Support: VROC NVMe SW RAID (0,1,5,10), PCIe RAID/HBA
-
Expansion / Connectivity
- PCIe Slots: Up to 10x PCIe Gen5 slots
- OCP Slots: 2x OCP 3.0 slots
- Networking: OCP adapters, PCIe 10/25/100/200 GbE
- GPU Support: Up to 10x SW GPUs or 2x DW GPUs
-
Redundancy & Reliability
- Power: Dual redundant AC/DC PSUs (Platinum/Titanium efficiency)
- Cooling: Lenovo Neptune Core/Air technology, redundant fans
- Reliability: Six nines uptime, hot-swap components
-
Operating System Support
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
-
Security Features
- Lenovo ThinkShield security suite
- Silicon Root of Trust
- Secure Boot and fTPM 2.0
- Federated directory security
-
Management & Monitoring
- Lenovo XClarity Controller: Embedded management
- XClarity One: AI-driven analytics
- APIs: Redfish APIs for automation
-
Warranty & Support
- Standard Warranty: 3 Years Customer Replaceable Unit, Onsite NBD 9x5
- Optional Support: Premier Support, TruScale Infrastructure Services
