Product Specification of DiskStation DS1821+ Storage
-
ProcessorAMD Ryzen™ V1500B quad-core 2.2 GHz
-
Memory4GB DDR4 ECC SODIMM (expandable up to 32GB)
-
Drive Bays8 bays (expandable up to 18 with DX517 x2)
-
Drive Support3.5" / 2.5" SATA HDD/SSD, 2 x M.2 NVMe 2280 SSD (cache only)
-
Max Internal Raw CapacityUp to 240TB (with expansions)
-
RAID SupportBasic, JBOD, RAID 0, 1, 5, 6, 10, Synology Hybrid RAID (SHR)
-
Network Ports4 x 1GbE RJ-45 (Link Aggregation/Failover supported)
-
PCIe Expansion1 x PCIe Gen3 x8 slot (for 10GbE NICs or M.2 SSD adapters)
-
USB Ports2 x USB 3.2 Gen 1
-
eSATA Portss2 x for DX517 expansion
-
Cooling2 x 120mm fans (adjustable speed)
-
Power Supply250W AC power adapter
-
Dimensions166 x 343 x 243 mm
-
Operating Temperature5°C to 35°C
-
SoftwareSynology DiskStation Manager (DSM 7.0+)
