Product Specification of PowerEdge R7615 Rack Server
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Single-socket (1 x 4th Gen AMD EPYC 9004 Series processor)
- Processor Family: 4th Generation AMD EPYC 9004 Series
- Max Sockets: 1
- Max Cores per Socket: Up to 128 cores
- Max TDP: Up to 400 W (varies by SKU)
- Max L3 Cache: Up to 256 MB per processor
- Memory Type: DDR5 RDIMM (registered ECC only)
- DIMM Slots: 12 DDR5 DIMM slots
- Maximum Capacity: Up to 3 TB
- Speed: Up to 4800 MT/s
- Protection: ECC with advanced RAS features
- Front Drive Bay Options: Up to 24 x 2.5-inch SAS/SATA/NVMe (max 368.64 TB)
- Configuration Option: Up to 16 x 2.5-inch SAS/SATA/NVMe (max 245.76 TB)
- Configuration Option: Up to 12 x 3.5-inch SAS/SATA (max 240 TB)
- Configuration Option: Up to 8 x 3.5-inch SAS/SATA (max 160 TB)
- Rear Drive Bays: Up to 4 x 2.5-inch SAS/SATA/NVMe
- RAID Support: PERC H965i, H755, H755N, H355, HBA355i controllers
- PCIe Slots: Multiple PCIe Gen5 slots (configuration dependent)
- Networking: LOM daughter card or OCP 3.0 (1/10/25 GbE options)
- GPU Support: Up to 3 x 300W DW or 6 x 75W SW GPUs
- Front Ports: 1x iDRAC Direct (Micro-AB USB), USB 3.2 Gen1
- Power: Redundant hot-plug PSUs (800W Platinum, 1100W Titanium, 1400W Platinum/Titanium, 1800W Titanium, 2400W Platinum)
- Cooling: Up to 6 hot-plug high-performance fans
- Reliability: Hot-swap components, tool-less serviceability
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux (RHEL)
- Canonical Ubuntu Server LTS
- VMware ESXi
- SUSE Linux Enterprise Server (SLES)
- Dell SafeBIOS Secure Core
- System Lockdown and Cryptographic Erase
- Firmware Update Verification and TPM 2.0
- Secure Boot and Multi-Factor Authentication
- iDRAC9 Enterprise: Embedded remote management
- Dell OpenManage Enterprise: Centralized management
- APIs: Redfish APIs for automation and orchestration
- Standard Warranty: 3 Years ProSupport (parts, labor, onsite)
- Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms
-
Server Type / Form Factor
- Type: Enterprise Rack Server
- Form Factor: 2U Rack
- Socket: Single-socket (1 x 4th Gen AMD EPYC 9004 Series processor)
-
Processor (CPU)
- Processor Family: 4th Generation AMD EPYC 9004 Series
- Max Sockets: 1
- Max Cores per Socket: Up to 128 cores
- Max TDP: Up to 400 W (varies by SKU)
- Max L3 Cache: Up to 256 MB per processor
-
Memory (RAM)
- Memory Type: DDR5 RDIMM (registered ECC only)
- DIMM Slots: 12 DDR5 DIMM slots
- Maximum Capacity: Up to 3 TB
- Speed: Up to 4800 MT/s
- Protection: ECC with advanced RAS features
-
Storage
- Front Drive Bay Options: Up to 24 x 2.5-inch SAS/SATA/NVMe (max 368.64 TB)
- Configuration Option: Up to 16 x 2.5-inch SAS/SATA/NVMe (max 245.76 TB)
- Configuration Option: Up to 12 x 3.5-inch SAS/SATA (max 240 TB)
- Configuration Option: Up to 8 x 3.5-inch SAS/SATA (max 160 TB)
- Rear Drive Bays: Up to 4 x 2.5-inch SAS/SATA/NVMe
- RAID Support: PERC H965i, H755, H755N, H355, HBA355i controllers
-
Expansion / Connectivity
- PCIe Slots: Multiple PCIe Gen5 slots (configuration dependent)
- Networking: LOM daughter card or OCP 3.0 (1/10/25 GbE options)
- GPU Support: Up to 3 x 300W DW or 6 x 75W SW GPUs
- Front Ports: 1x iDRAC Direct (Micro-AB USB), USB 3.2 Gen1
-
Redundancy & Reliability
- Power: Redundant hot-plug PSUs (800W Platinum, 1100W Titanium, 1400W Platinum/Titanium, 1800W Titanium, 2400W Platinum)
- Cooling: Up to 6 hot-plug high-performance fans
- Reliability: Hot-swap components, tool-less serviceability
-
Operating System Support
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux (RHEL)
- Canonical Ubuntu Server LTS
- VMware ESXi
- SUSE Linux Enterprise Server (SLES)
-
Security Features
- Dell SafeBIOS Secure Core
- System Lockdown and Cryptographic Erase
- Firmware Update Verification and TPM 2.0
- Secure Boot and Multi-Factor Authentication
-
Management & Monitoring
- iDRAC9 Enterprise: Embedded remote management
- Dell OpenManage Enterprise: Centralized management
- APIs: Redfish APIs for automation and orchestration
-
Warranty & Support
- Standard Warranty: 3 Years ProSupport (parts, labor, onsite)
- Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms
