Server Type / Form Factor |
- Type: Tower Server (convertible to rack)
- Form Factor: 4U Tower (Rack-mountable with optional kit)
- Socket: Dual-socket (supports up to 2 processors)
|
- Type: Tower Server
- Form Factor: 4U rackable tower
- Socket: Dual socket (supports 2nd Gen Intel Xeon Scalable Platinum/Silver up to 125 W per CPU)
|
|
Processor (CPU) |
- Processor Family: 4th and 5th Gen Intel® Xeon® Scalable Processors
- Max Supported: Up to 60 cores per CPU (e.g., Intel Xeon Gold 6490N)
- Architecture: Intel 7 (10nm Enhanced SuperFin)
- Max TDP: Up to 350W per processor
|
- Supported CPUs: Up to two 2nd Generation Intel Xeon Scalable processors (Platinum/Silver up to 125 W)
|
|
Memory (RAM) |
- Type: DDR5 Registered DIMMs (RDIMMs)
- DIMM Slots: 32 DIMM slots (16 per CPU)
- Max Capacity: Up to 8TB (with Intel Optane Persistent Memory)
- Speed: Up to 5600 MT/s
- Protection: ECC, Advanced Memory Mirroring, Lockstep
|
- Memory Type: TruDDR4 ECC Registered
- DIMM Slots: 12 slots total (6 per CPU)
- Max Capacity: Up to 768 GB with 64 GB DIMMs
- Speed: Up to 2933 MT/s (2666 MT/s also supported)
|
|
Storage |
- Drive Bays: Up to 12x LFF or 24x SFF (hot-plug front bays)
- Optional: Rear and NVMe options available
- Supported Types: SAS, SATA, NVMe
- RAID: HPE Smart Array Controllers (RAID 0, 1, 5, 6, 10, 50, 60)
- Max Capacity: Over 400TB+ depending on configuration
|
- Drive Bay Options:
- Up to 16 × 2.5 SAS/SATA hot swap bays (including up to 4 NVMe)
- Or up to 8 × 3.5 hot swap bays
- Plus up to 4 × 2.5 internal bays + 2 × M.2 boot drives
- Controllers: Software RAID standard; optional hardware RAID and up to 16 port HBAs available
|
|
Expansion / Connectivity |
- PCIe Slots: Up to 8x PCIe Gen5 slots (dependent on riser config)
- Networking: OCP 3.0 Slot (1/10/25/100GbE options)
- GPU Support: Supports up to 2x double-width or 4x single-width GPUs
|
- PCIe Slots: Up to 6 × PCIe 3.0 slots (with 2 CPUs installed)
- Networking: 2 × 1 GbE LOM standard; optional NICs via PCIe
|
|
Redundancy & Reliability |
- Power: Redundant Hot-Plug Power Supplies (800W, 1600W, 2400W)
- Cooling: Redundant Hot-Plug Fans
- Drive Redundancy: RAID configuration via Smart Array
- Security: HPE Silicon Root of Trust
|
- Power Supplies: 1 × fixed 450 W Gold PSU; or 2 × hot swap redundant PSUs (550 W/750 W/1100 W Platinum, or 750 W Titanium)
- Cooling: Hot swap chassis fans, chassis intrusion switch; drive/tray redundancy
|
|
Operating System Support |
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
- Canonical Ubuntu, Oracle Linux
|
- Microsoft Windows Server
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware vSphere / ESXi
|
|
Security Features |
- Silicon Root of Trust
- TPM 2.0 (Standard or FIPS-certified optional)
- Secure Boot & Secure Erase
- Firmware Runtime Verification
- Chassis Intrusion Detection
|
- Lenovo ThinkShield (lockable bezel, Kensington lock slot, chassis intrusion)
- TPM 1.2 and TPM 2.0 supported
- Predictive Failure Analysis, hot swap redundant drives and PSUs
|
|
Management & Monitoring |
- iLO 6: HPE Integrated Lights-Out for remote server management
- Management Tools: HPE OneView, HPE InfoSight Predictive Analytics
- API Support: Redfish and RESTful API
|
- Lenovo XClarity Controller (embedded) with XClarity Administrator support
- Includes Redfish API support and XClarity Integrator and Energy Manager plugins
|
|
Warranty & Support |
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (Next Business Day)
- Optional Services: HPE Pointnext Tech Care, Foundation Care, and Proactive Care
|
- Standard Warranty: 3 Years Warranty
- Support Options: Warranty extensions available via Lenovo service offerings
|
