Product Specification of HPE ProLiant Compute DL384 Gen12
- Type: Enterprise AI Rack Server
- Form Factor: 2U Air-Cooled Rack Server (19-inch)
- Socket: Dual NVIDIA GH200 Grace Hopper™ Superchips (NVL2)
- Processor Family: NVIDIA Grace CPU + NVIDIA Hopper GPU (Grace Hopper™ Superchip)
- Superchips per Server: Up to 2 NVIDIA GH200 Grace Hopper™ Superchips (NVL2)
- CPU Cores: 72 Arm Neoverse V2 cores per Grace CPU
- CPU per Superchip: 1 NVIDIA Grace CPU
- GPU per Superchip: 1 NVIDIA Hopper GPU
- Total Coherent Memory: Up to 1,248 GB
- Memory Type: LPDDR5X with ECC + HBM3e
- CPU Memory: Up to 480 GB LPDDR5X per Superchip
- GPU Memory: Up to 144 GB HBM3e per Superchip
- Maximum Memory per Superchip: Up to 624 GB Fast-Access Memory
- Maximum System Memory: Up to 1,248 GB Coherent Memory (Dual Superchip Configuration)
- Memory Protection: Error-Correction Code (ECC)
- Drive Support: Up to 8 EDSFF NVMe Gen5 Drives
- Drive Type: EDSFF NVMe Gen5 SSDs
- RAID Support: Hardware RAID controllers are not supported for M.2 or EDSFF NVMe drives
- PCIe Slots: Up to 4 PCIe Gen5 x16 expansion slots
- Expansion Options: Up to 4 PCIe Full Height Half Length (FHHL) slots, or 2 PCIe FHHL slots with 2 OCP 3.0 slots
- OCP Slots: Up to 2 OCP 3.0 slots
- Power Supply: Up to 4 × HPE 1800W–2200W Flex Slot Titanium Hot-Plug Power Supplies
- Power Redundancy: Single GH200: 2+0, 2+1, or 2+2; Dual GH200 NVL2: 3+1 redundancy
- Cooling: 6 Hot-Plug Redundant System Fans
- Availability Features: Enterprise-class redundant cooling and power architecture for AI workloads
- Red Hat Enterprise Linux (RHEL) 9.2+
- SUSE Linux Enterprise Server (SLES)
- Canonical Ubuntu
- HPE Silicon Root of Trust
- Secure Boot
- Secure Firmware Validation
- Runtime Firmware Verification
- Trusted Platform Security through HPE iLO
- HPE iLO Standard: Embedded server management with Intelligent Provisioning
- HPE iLO Advanced: Advanced remote management, monitoring, firmware updates, and remote console
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite Support
- Optional Support: HPE Foundation Care, HPE Proactive Care, HPE Pointnext Services, and customized enterprise support plans
-
Server Type / Form Factor
- Type: Enterprise AI Rack Server
- Form Factor: 2U Air-Cooled Rack Server (19-inch)
- Socket: Dual NVIDIA GH200 Grace Hopper™ Superchips (NVL2)
-
Processor (CPU)
- Processor Family: NVIDIA Grace CPU + NVIDIA Hopper GPU (Grace Hopper™ Superchip)
- Superchips per Server: Up to 2 NVIDIA GH200 Grace Hopper™ Superchips (NVL2)
- CPU Cores: 72 Arm Neoverse V2 cores per Grace CPU
- CPU per Superchip: 1 NVIDIA Grace CPU
- GPU per Superchip: 1 NVIDIA Hopper GPU
- Total Coherent Memory: Up to 1,248 GB
-
Memory (RAM)
- Memory Type: LPDDR5X with ECC + HBM3e
- CPU Memory: Up to 480 GB LPDDR5X per Superchip
- GPU Memory: Up to 144 GB HBM3e per Superchip
- Maximum Memory per Superchip: Up to 624 GB Fast-Access Memory
- Maximum System Memory: Up to 1,248 GB Coherent Memory (Dual Superchip Configuration)
- Memory Protection: Error-Correction Code (ECC)
-
Storage
- Drive Support: Up to 8 EDSFF NVMe Gen5 Drives
- Drive Type: EDSFF NVMe Gen5 SSDs
- RAID Support: Hardware RAID controllers are not supported for M.2 or EDSFF NVMe drives
-
Expansion / Connectivity
- PCIe Slots: Up to 4 PCIe Gen5 x16 expansion slots
- Expansion Options: Up to 4 PCIe Full Height Half Length (FHHL) slots, or 2 PCIe FHHL slots with 2 OCP 3.0 slots
- OCP Slots: Up to 2 OCP 3.0 slots
-
Redundancy & Reliability
- Power Supply: Up to 4 × HPE 1800W–2200W Flex Slot Titanium Hot-Plug Power Supplies
- Power Redundancy: Single GH200: 2+0, 2+1, or 2+2; Dual GH200 NVL2: 3+1 redundancy
- Cooling: 6 Hot-Plug Redundant System Fans
- Availability Features: Enterprise-class redundant cooling and power architecture for AI workloads
-
Operating System Support
- Red Hat Enterprise Linux (RHEL) 9.2+
- SUSE Linux Enterprise Server (SLES)
- Canonical Ubuntu
-
Security Features
- HPE Silicon Root of Trust
- Secure Boot
- Secure Firmware Validation
- Runtime Firmware Verification
- Trusted Platform Security through HPE iLO
-
Management & Monitoring
- HPE iLO Standard: Embedded server management with Intelligent Provisioning
- HPE iLO Advanced: Advanced remote management, monitoring, firmware updates, and remote console
-
Warranty & Support
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite Support
- Optional Support: HPE Foundation Care, HPE Proactive Care, HPE Pointnext Services, and customized enterprise support plans
