Product Specification of HPE ProLiant Compute DL320 Gen12
- Type: Enterprise Rack Server
- Form Factor: 1U Rack
- Socket: Single-socket (1 x Intel Xeon 6 P-core processor)
- Processor Family: Intel Xeon 6 (Rich I/O P-core series)
- Max Sockets: 1
- Max Cores per Socket: Up to 144 cores
- Max TDP: Up to 350 W (varies by CPU model)
- Memory Channels: 8 channels per processor
- Memory Type: HPE DDR5 Smart Memory (RDIMM)
- DIMM Slots: 16 DIMM slots
- Maximum Capacity: Up to 4 TB (with 256 GB modules)
- Speed: Up to 6400 MT/s memory (1DPC)
- Protection: ECC and advanced RAS features
- Drive Bays (Front): Up to 20 EDSFF E3.S NVMe drive bays
- SFF Options: 2 SFF x4 Tri-Mode 24G U.3 BC drive cages
- Backplane Options: 8 SFF x1 or x4 Tri-Mode 24G U.3 BC backplanes
- Boot Options: Optional NS204i-u Hot-Plug Boot Device (front or rear)
- Storage Controllers: HPE OCP-type RAID (OROC) or PCIe-based controllers
- PCIe Slots: Multiple PCIe 5.0 x16-style slots (primary and secondary riser configuration)
- OCP Slots: Front or rear OCP 3.0 networking slots (1 Gb / 10 Gb / higher options)
- GPU Support: Up to four single-wide GPUs or two double-wide GPUs (configuration dependent)
- Ports / I-O: USB 3.2 Gen1 front ports
- Video Options: Optional DisplayPort / VGA via DC-SCM
- Management Port: Dedicated iLO service port
- Power: Modular Common Redundant Power Supply (M-CRPS) design; redundant hot-plug power supplies optional
- Cooling: Integrated system fan array (7 fans) with hot-swap capability
- Availability Features: DC-MHS-based hot-swap components, quick-removal access panel, and enterprise-grade serviceability
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
- Canonical Ubuntu
- Oracle Linux
- HPE iLO 7 security and secure boot
- Intel-based hardware security (P-core protections and Rich I-O options)
- UEFI-managed firmware integrity and TPM-class key management
- Data-at-rest protection via HPE-approved self-encrypting and encrypted-drive options
- HPE iLO 7: Remote console, firmware updates, and configuration
- Redfish API: Support for orchestration and integration
- HPE Tools: Cloud operating experience and modular hardware-management capabilities
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (region- and contract-dependent)
- Optional Support: HPE Pointnext services, Foundation Care, Proactive Care, and custom SLAs for edge, SMB, and ROBO deployments
-
Server Type / Form Factor
- Type: Enterprise Rack Server
- Form Factor: 1U Rack
- Socket: Single-socket (1 x Intel Xeon 6 P-core processor)
-
Processor (CPU)
- Processor Family: Intel Xeon 6 (Rich I/O P-core series)
- Max Sockets: 1
- Max Cores per Socket: Up to 144 cores
- Max TDP: Up to 350 W (varies by CPU model)
- Memory Channels: 8 channels per processor
-
Memory (RAM)
- Memory Type: HPE DDR5 Smart Memory (RDIMM)
- DIMM Slots: 16 DIMM slots
- Maximum Capacity: Up to 4 TB (with 256 GB modules)
- Speed: Up to 6400 MT/s memory (1DPC)
- Protection: ECC and advanced RAS features
-
Storage
- Drive Bays (Front): Up to 20 EDSFF E3.S NVMe drive bays
- SFF Options: 2 SFF x4 Tri-Mode 24G U.3 BC drive cages
- Backplane Options: 8 SFF x1 or x4 Tri-Mode 24G U.3 BC backplanes
- Boot Options: Optional NS204i-u Hot-Plug Boot Device (front or rear)
- Storage Controllers: HPE OCP-type RAID (OROC) or PCIe-based controllers
-
Expansion / Connectivity
- PCIe Slots: Multiple PCIe 5.0 x16-style slots (primary and secondary riser configuration)
- OCP Slots: Front or rear OCP 3.0 networking slots (1 Gb / 10 Gb / higher options)
- GPU Support: Up to four single-wide GPUs or two double-wide GPUs (configuration dependent)
- Ports / I-O: USB 3.2 Gen1 front ports
- Video Options: Optional DisplayPort / VGA via DC-SCM
- Management Port: Dedicated iLO service port
-
Redundancy & Reliability
- Power: Modular Common Redundant Power Supply (M-CRPS) design; redundant hot-plug power supplies optional
- Cooling: Integrated system fan array (7 fans) with hot-swap capability
- Availability Features: DC-MHS-based hot-swap components, quick-removal access panel, and enterprise-grade serviceability
-
Operating System Support
- Microsoft Windows Server
- Red Hat Enterprise Linux (RHEL)
- SUSE Linux Enterprise Server (SLES)
- VMware ESXi
- Canonical Ubuntu
- Oracle Linux
-
Security Features
- HPE iLO 7 security and secure boot
- Intel-based hardware security (P-core protections and Rich I-O options)
- UEFI-managed firmware integrity and TPM-class key management
- Data-at-rest protection via HPE-approved self-encrypting and encrypted-drive options
-
Management & Monitoring
- HPE iLO 7: Remote console, firmware updates, and configuration
- Redfish API: Support for orchestration and integration
- HPE Tools: Cloud operating experience and modular hardware-management capabilities
-
Warranty & Support
- Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (region- and contract-dependent)
- Optional Support: HPE Pointnext services, Foundation Care, Proactive Care, and custom SLAs for edge, SMB, and ROBO deployments
