Product Specification of Heidi CP 51L ID Card Printer
- Direct Dye-Sublimation
- Edge-to-Edge Printing
- Laminating Mode: Single & Dual
- Lamination Film: Clear & Holographic (0.6mil, 1.0mil)
- ISO CR80
- ISO CR79 (Factory-installed option)
- 300 dpi (Color & Monochrome)
- 600 dpi & 1200 dpi (Monochrome only)
- Monochrome: Up to 5 sec/card (720 cards/hour)
- YMCKO: Up to 17 sec/card (212 cards/hour)
- YMCKOK: Up to 22 sec/card (164 cards/hour)
- With Lamination (Simultaneous):
- YMCK + Single Lamination: 22 sec/card
- YMCKK + Single Lamination: 32 sec/card
- With Lamination (One by One):
- YMCK + Single Lamination: 43 sec/card
- YMCKK + Single Lamination: 53 sec/card
- Magnetic Stripe Encoder
- ISO 7811 (Track I, II, III Read/Write, HiCo/LoCo), JIS II
- Contact Smart Card Encoder
- ISO 7816 A/B/C, ISO 7816 1/2/3/4 Microprocessor Cards
- Contactless Smart Card Encoder
- ISO 14443 Type A/B
- MIFARE, DESFire, iCLASS
- ISO 18092 (NFC), Felica
- USB
- Ethernet
- Wi-Fi (Optional)
- Input Hopper:
- 100 Cards
- 200 Cards (Cover open)
- Output Hopper:
- Front: 40 Cards
- Rear: 100 Cards (Optional rear-side stacker)
- Microsoft Windows 7 / 8 / 10
- macOS
- Linux
- Certifications: CB, CE, FCC, KC, CCC
- Physical Security:
- Input Hopper, Ribbon & Film Lock (Optional)
- Kensington Lock (Optional)
- Power Supply: Free Voltage (AC 100–220V, 50–60Hz)
- Power Consumption: 96W
- Operating Temperature: 15°C – 35°C
- Operating Humidity: 35% – 70%
- Weight: Approx. 8.8 kg (19.4 lbs)
-
Print Technology
- Direct Dye-Sublimation
- Edge-to-Edge Printing
- Laminating Mode: Single & Dual
- Lamination Film: Clear & Holographic (0.6mil, 1.0mil)
-
Card Size Compatibility
- ISO CR80
- ISO CR79 (Factory-installed option)
-
Card Thickness0.38 mm (15 mil) to 1.0 mm (40 mil)
-
Print Resolution
- 300 dpi (Color & Monochrome)
- 600 dpi & 1200 dpi (Monochrome only)
-
Single/Dual-Sided PrintingDual-Sided Printing (Standard)
-
Print Speed
- Monochrome: Up to 5 sec/card (720 cards/hour)
- YMCKO: Up to 17 sec/card (212 cards/hour)
- YMCKOK: Up to 22 sec/card (164 cards/hour)
- With Lamination (Simultaneous):
- YMCK + Single Lamination: 22 sec/card
- YMCKK + Single Lamination: 32 sec/card
- With Lamination (One by One):
- YMCK + Single Lamination: 43 sec/card
- YMCKK + Single Lamination: 53 sec/card
-
Encoding Options
- Magnetic Stripe Encoder
- ISO 7811 (Track I, II, III Read/Write, HiCo/LoCo), JIS II
- Contact Smart Card Encoder
- ISO 7816 A/B/C, ISO 7816 1/2/3/4 Microprocessor Cards
- Contactless Smart Card Encoder
- ISO 14443 Type A/B
- MIFARE, DESFire, iCLASS
- ISO 18092 (NFC), Felica
-
Connectivity
- USB
- Ethernet
- Wi-Fi (Optional)
-
Media Capacity
- Input Hopper:
- 100 Cards
- 200 Cards (Cover open)
- Output Hopper:
- Front: 40 Cards
- Rear: 100 Cards (Optional rear-side stacker)
-
Software Compatibility
- Microsoft Windows 7 / 8 / 10
- macOS
- Linux
-
Warranty & Support
- Certifications: CB, CE, FCC, KC, CCC
- Physical Security:
- Input Hopper, Ribbon & Film Lock (Optional)
- Kensington Lock (Optional)
- Power Supply: Free Voltage (AC 100–220V, 50–60Hz)
- Power Consumption: 96W
- Operating Temperature: 15°C – 35°C
- Operating Humidity: 35% – 70%
- Weight: Approx. 8.8 kg (19.4 lbs)
