Server Type / Form Factor |
- Type: Rack Server
- Form Factor: 2U Rackmount
- Socket: Dual socket (supports 4th and 5th Gen Intel Xeon Scalable)
|
- Type: Rack Server
- Form Factor: 2U Rackmount
- Socket: Dual-socket (supports 2 CPUs)
|
|
Processor (CPU) |
- Supported CPUs: Up to two 5th Gen Intel Xeon Scalable (up to 28 cores/socket)
- Also supports: 4th Gen Intel Xeon Scalable (up to 32 cores/socket)
|
- Supported CPUs: Up to 2 × 4th Gen Intel Xeon Scalable (up to 56 cores/socket) or 2 × 5th Gen Intel Xeon Scalable (up to 64 cores/socket)
- Optional: Intel QuickAssist Technology
|
|
Memory (RAM) |
- Memory Type: DDR5 RDIMM ECC
- DIMM Slots: 16 slots total
- Max Capacity: Up to 1.5 TB
- Speed: Up to 5200 MT/s
|
- Memory Type: DDR5 RDIMM ECC
- DIMM Slots: 32 memory slots (16 per CPU)
- Max Capacity: Up to 8 TB via RDIMM
- Speed: Supports up to 4800 MT/s
|
|
Storage |
- Drive Bay Options:
- Up to 8 × 3.5 SAS/SATA (max ~192 TB)
- Up to 12 × 3.5 SAS/SATA (max ~288 TB)
- Up to 8 × 2.5 SAS/SATA/NVMe (max ~122.9 TB)
- Up to 16 × 2.5 SAS/SATA/NVMe (max ~121.6-244.5 TB mixed)
- Rear Bays: 1–2 × 2.5 SAS/SATA/NVMe (~30.7 TB)
- Controllers: PERC H965i, H755, H755N, H355, HBA355i, HBA465i; BOSS N1 dual M.2 boot; Software RAID S160
|
- Front Drive Bays (config dependent):
- Up to 12 × 3.5 SAS/SATA (max 240 TB)
- 8 × 2.5 SAS/SATA/NVMe (max 122.88 TB)
- 16 × 2.5 SAS/SATA/NVMe (max 245.76 TB)
- 24 × 2.5 SAS/SATA/NVMe (max 368.64 TB)
- Rear Drive Bays: Options with 2 or 4 × 2.5 drives (up to ~61.44 TB)
- Controllers: PERC H965i, H755, H355, HBA355i; BOSS N1 dual M.2 boot; Software RAID S160
|
|
Expansion / Connectivity |
- PCIe Slots: CPU/config dependent; up to 4 (1 CPU) or 6 (2 CPU) slots, mix of Gen4/Gen5 x16/x8
- Networking: Embedded dual 1 GbE LOM; optional OCP 3.0 mezzanine slot
|
- PCIe Slots: Up to 8 slots: mix of PCIe Gen4 and Gen5, full height and low profile
- GPU Support: Supports 2 × double-width (350 W) or 6 × single-width (75 W) GPUs
- Networking: Embedded dual 1 GbE LOM; optional OCP 3.0 mezzanine networking
|
|
Redundancy & Reliability |
- Power Supplies: Hot plug redundant PSUs (600W–1800W AC or DC Titanium/Platinum options)
- Cooling: Up to 6 hot swap fans; high performance fan options
|
- Power Supplies: Hot plug redundant options: 800 W, 1100 W, 1400 W, 1800 W, 2400 W, 2800 W (Titanium/Platinum AC/DC)
- Cooling: Multiple hot swap fans; optional direct liquid cooling
|
|
Operating System Support |
- Microsoft Windows Server with Hyper V
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware ESXi
- Canonical Ubuntu Server LTS
|
- Microsoft Windows Server (with Hyper V)
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware ESXi
- Ubuntu Server LTS
|
|
Security Features |
- Cryptographically signed firmware and Silicon based Root of Trust
- Secure Boot, Secure Erase, System Lockdown (iDRAC Enterprise/Datacenter required)
- TPM 2.0 (FIPS, CC TCG certified)
|
- Silicon Root of Trust with cryptographically signed firmware
- Secure Boot, Secure Erase, System Lockdown (iDRAC Enterprise required)
- TPM 2.0 support (FIPS, CC TCG Certified)
|
|
Management & Monitoring |
- iDRAC9 with Lifecycle Controller, iDRAC Direct USB port
- RESTful Redfish API; iDRAC Service Module
- Tools: Dell OpenManage Enterprise, CloudIQ, Integrations with VMware, Microsoft, Ansible, Terraform
|
- Embedded iDRAC9 with Lifecycle Controller and iDRAC Direct (USB)
- RESTful Redfish API; iDRAC Service Module
- Management Tools: Dell OpenManage Enterprise, CloudIQ, integration plugins
|
|
Warranty & Support |
- Standard Limited Hardware Warranty:
3 years of coverage that includes parts, labor, and Next Business Day Onsite service
|
- Standard Warranty: 3 Year ProSupport with Next Business Day Onsite Service
- Upgrades: Optional ProSupport Plus or Mission Critical services
|
