Product Specification of Heidi CP 55 S Single side ID Card Printer
Dye-sublimation / Resin Thermal Transfer (direct-to-card)
CR-80
15 mil – 40 mil (0.38 mm – 1.0 mm)
300 dpi (11.8 dots/mm)
Single-sided, upgradable to dual with optional flipper module
- Color (YMCKO): up to 170 cph
- Black Overlay (KO): up to 360 cph
- Monochrome (Black): up to 720 cph
Magnetic stripe (ISO 7811), Contact smart card (ISO/IEC 7816), Contactless smart card (ISO 14443 A/B, MIFARE, iCLASS, DESFire), Dual contact/contactless encoder, plus physical lock. Options can be combined and added onsite or at factory.
USB 2.0 standard; Ethernet optional (TCP/IP 10/100)
Input hopper: 100 cards (200 with cover open); Output hopper: 40 cards (up to 100 with rear stacker)
Not available on this model
Compatible with Infome’s InfoID Custom Card Printing Software
24-month standard warranty on printer & print head (depot); after-sales support from Infome
-
Print Technology
Dye-sublimation / Resin Thermal Transfer (direct-to-card)
-
Card Size Compatibility
CR-80
-
Card Thickness
15 mil – 40 mil (0.38 mm – 1.0 mm)
-
Print Resolution
300 dpi (11.8 dots/mm)
-
Single/Dual-Sided Printing
Single-sided, upgradable to dual with optional flipper module
-
Print Speed
- Color (YMCKO): up to 170 cph
- Black Overlay (KO): up to 360 cph
- Monochrome (Black): up to 720 cph
-
Encoding Options
Magnetic stripe (ISO 7811), Contact smart card (ISO/IEC 7816), Contactless smart card (ISO 14443 A/B, MIFARE, iCLASS, DESFire), Dual contact/contactless encoder, plus physical lock. Options can be combined and added onsite or at factory.
-
Connectivity
USB 2.0 standard; Ethernet optional (TCP/IP 10/100)
-
Media Capacity
Input hopper: 100 cards (200 with cover open); Output hopper: 40 cards (up to 100 with rear stacker)
-
Laminate Options
Not available on this model
-
Software Compatibility
Compatible with Infome’s InfoID Custom Card Printing Software
-
Warranty & Support
24-month standard warranty on printer & print head (depot); after-sales support from Infome
